| Type |
Infinity-correctedOptical intermediate attachment tube |
| Objectives |
5X-250X |
| Field number |
22 (real field number 11mm) |
| Intermediate magnification |
2X |
| Optical path exchange |
CF confocal/direct optical paths |
| CF mode exchange |
CF1: Priority on contrast(recommended objectives 10X-200X)
CF2: Priority on brightness(recommended objectives 100x, 150X) |
| Confocal illumination |
100W mercury lamp |
| Power supply |
AC adapter U-ACAD4515(100-220V/220-240V~0.4A/0.2A) |
| Dimensions & weight |
W288 x D330 x H130(mm)Approx. 5.4kg |
